Mac Pro Slotted Wide Boy Jig Square – Modular Fixture Alignment Tool

Description

 Modular design to be used with a fixture jig tables with 16mm through holes on 25/50mm centres

Unlike cast ground (Expensive) squares WeldTrue Squares are manufactured as self-build kits giving you accurate low cost tooling.

Note: Some images are a computer rendering representation of the product therefore colour & finish may differ.

FEATURES

• Engineered in house heat dissipating waved key and slots interlock
• Manufactured from 6mm S275 HRPO Mild Steel (Superior)
• All parts highly accurate CNC Laser cut.
• 16mm securing hole 25mm apart on centres to work with all 16mm tooling and tables
• Precision tooling when constructed correctly
• Can be used and secured both vertical or Horizontal
• Laser cut with a guaranteed tolerance of +/-0.1m
• Designed and manufactured in the UK

MEASUREMENTS

1no. MAC PRO Slotted Square Wide Boy 150x150x200

 BUILD OPTIONS

1- Self-build – Delivered flat packed ready to self-weld.

2- Pre-Constructed – Mac Industries assemble, weld and quality check your item. (Additional Charge)
