Mac Pro Slim Jim Starter Set – Compact Modular Jig Square System

Description

Modular design to be used with a fixture jig tables with 16mm through holes on 25/50mm centres

Unlike cast ground (Expensive) squares WeldTrue Squares are manufactured as self-build kits giving you accurate low cost tooling.

Note: Some images are a computer rendering representation of the product therefore colour & finish may differ.

FEATURES

• Engineered in house heat dissipating waved key and slots interlock
• Manufactured from 6mm S275 HRPO Mild Steel (Superior)
• All parts highly accurate CNC Laser cut.
• 16mm securing hole 25mm apart on centres to work with all 16mm tooling and tables
• Precision tooling when constructed correctly
• Can be used and secured both vertical or Horizontal
• Laser cut with a guaranteed tolerance of +/-0.1m
• Designed and manufactured in the UK

KIT CONTAINS

1no. WeldTrue ProSQ Mini Slim Jim Square 150x150x50

1no. WeldTrue ProSQ Mid Slim Jim Square 150x250x50

1no. WeldTrue ProSQ Tall Slim Jim 450x200x50

BUILD OPTIONS

1- Self-build – Delivered flat packed ready to self-weld.

2- Pre-Constructed – Mac Industries assemble, weld and quality check your item. (Additional Charge)
