Mac Pack Of 2 × 150Mm Slotted Stop Tabs – Precision Fixture Positioning

Description

2x Mac 10mm Thick 150mm Slotted Stop Tabe

Modular design to be used with a fixture jig tables with 16mm through holes on 25/50mm centres

Note: Some images are a computer rendering representation of the product therefore colour & finish may differ.

FEATURES

• Manufactured from 10mm S275 HRPO Mild Steel (Superior)
• All parts highly accurate CNC Fibre Laser cut.
• 16mm securing hole 25mm apart on centres to work with all 16mm tooling and tables
• Precision tooling when constructed correctly
• Laser cut with a guaranteed tolerance of +/-0.1m
• Designed and manufactured in the UK

Measurements

A- 150mm

B- 50mm

C- 10mm

NOTE: SHOULDER BOLTS AND HARDWARE NOT INCLUDED
